108076-1-ORNG
-
MODEL SPECS
Model Name: Mini XRT Model Type: Monster Truck Top Speed: 55+ Skill Level: 1 Scale: Mini Length: 14.8 inches (376 mm) Width: 11 inches (279 mm) Height: 5 inches (127 mm) Weight: 3.99 pounds (1.81 kg) Front Track: 11 inches (279 mm) Rear Track: 11 inches (279 mm) MOTOR SPECS
Motor Name: Velineon® 3500 Motor Type: Sensorless brushless Motor Weight: 9.24 ounces (262 g) Motor Length: 3.03 inches (77 mm) overall length, 2.2 inches (56 mm) can length Motor Diameter: 1.41 inches (36 mm) Motor Shaft Size: 3 mm Motor Connector Type: 3.5 mm bullet ESC SPECS
ESC Name: VXL-3s electronic speed control ESC Type: Brushless ESC Case Size: 1.54 inches (39 mm) / 2.18 inches (55 mm) / 1.30 inches (33 mm) ESC Weight: 3.17 ounces (90 g) Motor Connectors: 3.5 mm bullet Battery Connectors: Traxxas High-Current Connector ESC Power Wire: 12 gauge Maxx Cable
- 40+ mph with included 2-cell LiPo Battery
- 55+ mph with optional 3-Cell LiPo Battery (sold separately)
- Clipless Body Mounting System
- Quick and easy installation and removal
- Nerf bar channels for side body support
- Reinforced for extra protection against tearing
- Functional rear wing
- VXL-3s™ Waterproof Electronic Speed Control
- Three programmable drive profiles
- Sport Mode - forward / brake / reverse
- Race Mode - forward / brake
- Training Mode™ - 50% forward / brake / 50% reverse
- Heat sink accepts accessory cooling fan (3340)
- Traxxas EZ-Set® one-button setup
- Built-in two-stage low-voltage detection
- Velineon® 3500 Kv Brushless Motor
- Ultra high-temperature sintered neodymium magnets
- Low-maintenance design
- Precision-balanced rotor
- Efficient high-speed ball bearings
- 3500 Kv
- Brilliant blue-anodized finish
- Battery and Charger Included
- High-capacity 2-cell LiPo battery
- 7.4 volts
- 3500 mAh for extended run time
- 2-amp USB-C charger
- iD® technology for faster, safer charging
- TQi™ 2.4 GHz High Output 2-Channel Radio System
- Programmable multi-function knob
- Adjustable steering and throttle percentage (dual rates)
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle end points
- 5-channel micro receiver (6533) with fail-safe security
- Patented waterproof receiver box with easy-access plug
- Traxxas Stability Management® (TSM)
- Improves straight line acceleration and braking on low-traction surfaces
- Maintains steering composure to allow throttle-on powerslides
- Never dulls throttle or slows the truck
- Adjusts from off to 100% assistance from the transmitter
- 1/10 Scale 4X4 Driveline
- Full-time shaft-driven 4-wheel drive
- 1/10 scale extreme-duty telescoping driveshafts
- Direct-drive (no transmission)
- Sealed center differential
- Large 32-pitch gears
- Sealed planetary steel-gear differentials (F&R)
- Fixed gear mesh system
- Modular Composite Chassis
- Modular chassis with interlocking front and rear bulkheads
- Driveline is sealed in the chassis to keep out dirt
- Absorbs and distributes impact energy
- Easy to service and access components
- Easy Battery Access
- Battery is protected deep in the chassis
- Battery hold-down pivots for easy access
- More secure than conventional retention systems
- Steering
- 1/10 scale 2075X waterproof high-torque, metal-gear servo
- Heavy-duty double-shear bellcranks
- Cam-operated servo saver
- Suspension
- Heavy duty, double-shear suspension arms
- Dual wishbone design
- Extra tough outer suspension components
- Oil-Filled Ultra Shocks™
- Full size 1/10 scale shocks
- Large oil capacity
- Easy to tune
- Bumpers and Skid Plates
- Tough energy absorbing front bumper
- High-angle front skid plate
- Rugged interlocking skid plates
- Smooth undertray eliminates snags
- Integrated nerf bars for side impact resistance
- Wheels and Tires
- New graphite gray mini XRT wheels
- Gravix® tires with foam inserts
- Excellent traction on or off the road
- Directional tread pattern for quieter running
- Thick center carcass resists ballooning
- Hex Hardware with Rust-Resistant Black Oxide Coating
- Sealed Ball Bearings
MODEL MODEL 108076-1: Mini XRT: Maxx-scale monster truck, fully assembled, Ready-To-Race®, with TQi™ 2.4 GHz radio system, Velineon® VXL-3s™ brushless power system, and clipless painted body. Includes 2-cell LiPo battery and 2-amp USB-C charger.What’s In The Box:
- Mini XRT Ready-To-Race monster truck
- Velineon VXL-3s brushless power system
- 3500 mAh 2-cell LiPo battery
- 2-amp USB-C charger
- Quick Start Guide
- TQi 2.4 GHz radio system
- High quality maintenance tools
What You’ll Need:
- AA Alkaline Batteries
Four AA alkaline batteries for the transmitter
- Charging Accessories
Power adapter 2912 and power cable 2916 recommended for peak charging performance
